Components
coil→data set→machine start→uncoiling→leveling→pre-roll forming→selective punching→cutting→conveyor→roll forming to bite seaming→product
Specification
- TF bracing roll former overview:
- 1. The rollers’ support is a whole one, all the dimensions is processed by machining centre. The distance (space) between top & bottom rollers is adjusted by eccentric sleeve on the top roller shaft. The lock device ensures stability of the machine. All the bearings on the top & bottom shafts are lubricated.
2. Module torii is installed on NMT, adjust the distance through rotation leader screw.
Technical parameters:
TF bracing roll former
Cutter System
| Serial number | Item | Unit | Parameters | Remark | |
| 1 | Suitable material | Type | Q235 | ||
| strength | MPa | ||||
| Thickness | mm | 0.8mm | |||
| Coil internal diameter | mm | 500mm | |||
| Coil weight | T | 3 | |||
| 2 | Specification | mm | 100-320 | ||
| 3 | Line speed | m/min | 35 | ||
| 4 | Roller material | D2 quenching treatment | |||
| 5 | Roller driven type | External chain transmission | |||
| 6 | Operating system | Windows2000 | |||
| 7 | Total motor power | Kw | About11 | ||
| 8 | Electric control system | PLC automatic control system | |||
| 9 | Dimension(L*W*H) | m | |||
