Components
Uncoiling –leveling- Looping—Feeding—punching —Roll forming—Cutting –Product rack
Specification
- Equipment overview:
- 1.Double cantilever gear drives, the producing width of machine is adjust continually, it is possible to change the width and height.
2. Rolling stations is 20 steps ,the main machine consists of AC motor,reducer,high precision liner rail, transmission box on left and right, horizontal adjustment system and rolling moulds. The machine base and transmission adopts welding structure , with hardness treatment, the material of roller is 45# steel.
3. The roll forming craft is made by the special Germany cold roll forming program COPRA; the craft is also made the FEA analysis and check. The structure of the rollers is combined, so the line speed difference and resisting force of roll forming is small. The sheet is easy to feed. All these assure the accuracy and stable of the roll forming.
Technical parameters:
This line with auto flow production functions of uncoiling, butt-welding, leveling, servo feeding, punching, roll forming and track cutting etc, perfectly achieve the joint of punching, roll forming and cutting One operator could run the whole line. Products with high precise, good quality appearance. Machine with stable feature, short production assistance time, production efficient could reach 20m/min.
| Serial number | Item | Unit | Parameters | Remark | |
| 1 | Suitable material | Type | CR,HR Sheet;Galvanized Sheet | ||
| strength | MPa | ≤350 | |||
| Thickness | mm | 1.6-3.2 | |||
| Coil internal diameter | mm | 500,600 | |||
| Coil weight | T | 5 | |||
| 2 | Specification | mm | 100-320 | ||
| 3 | Line speed | m/min | 25 | ||
| 4 | Roller material | D2 quenching treatment | |||
| 5 | Roller driven type | External chain transmission | |||
| 6 | Operating system | Windows2000 | |||
| 7 | Total motor power | Kw | About 65 | ||
| 8 | Electric control system | PLC automatic control system | |||
| 9 | Dimension(L*W*H) | m | 30X2X1.7 | ||
